WACKER NEUSON BS62-4 RAMMER JUMPING JACK 11" PLASTIC SHOE
Sale price
329900
$3,299.00
Regular price
$4,340.00
Unit price
WACKER NEUSON BS62-4 RAMMER JUMPING JACK 11" PLASTIC SHOE is backordered and will ship as soon as it is back in stock.
Pickup available at 7 15th Street
Usually ready in 24 hours
Delivery and Shipping
Delivery and Shipping
Please contact us for shipping.
WACKER NEUSON BS62-4 RAMMER JUMPING JACK 11" PLASTIC SHOE
Sale price
329900
$3,299.00
Regular price
$4,340.00
Unit price
Description
Description
NEW 2026 WACKER NEUSON BS62-4 RAMMER WITH 11" PLASTIC SHOE. 3.5HP HONDA ENGINE. Highlights Large stroke, high impact force Just one lever for starting, idling and stopping Efficient air filter Ergonomic guide handle Low oil warning indicator
WEIGHT: 141LBS
DIMENSIONS: 26.1"X13.7"X36.2"
| OPERATING FLUIDS | Metric | Imperial |
| Oil volume | 0,700 l | 0,185 gal US |
| Oil specification | SAE 10W-40 | SAE 10W-40 |
| ENGINE | Metric | Imperial | ||
| Fuel management | Carburettor | Carburettor | ||
| Engine operating mode | four-stroke | four-stroke | ||
| Operating Engine speed | 3.950 1/min | 3.950 1/min | ||
| Fuel consumption | 0,75 kg/h | 1,00 L/Std | 1,7 lb/h | 0,3 GPH US |
| CO2 (NRSC) | 674,00 g/KWh | 674,00 g/KWh | ||
| Standard (Power max.) | SAE J1349 | SAE J1349 | ||
| Standard (Effective power) | SAE J1349 | SAE J1349 | ||
| Tank capacity | 3,00 l | 0,8 gal US | ||
| Nominal Engine speed | 3.600 1/min | 3.600 1/min | ||
| Oil filling max. | 0,30 l | 0,1 gal US | ||
| Effective power | 2,7 kW, 2,3 kW | 3,6 hp, 3,1 hp | ||
| fuel type | Gasoline | Gasoline | ||
| Cooling | air cooling | air cooling | ||
| Exhaust-gas limit | US Phase 3, EU Stage V, China Stage 2 | US Phase 3, EU Stage V, China Stage 2 | ||
| Oil specification | SAE 10W-40 | SAE 10W-40 | ||
| Starter type | Recoil starter | Recoil starter | ||
| Upper idling speed ex load | 1.850 1/min | 1.850 1/min | ||
| Operating power | 2,7 kW | 3,6 hp | ||
| Engine type | Gasoline engine | Gasoline engine | ||
| Cylinder | 1 | 1 | ||
| Engine Manufacturer | Honda | Honda | ||
| Standard (Operating power) | ISO 3046-1 | ISO 3046-1 | ||
| Cylinder capacity | 121 cm3 | 7,4 Inch3 | ||
| Spark plug(s) | DENSO U16FSR-UB, NGK CR5HSB | DENSO U16FSR-UB, NGK CR5HSB | ||
| Engine Designation | GXR120RT-KR-W1-SD | GXR120RT-KR-W1-SD |
| MECHANICAL - OUTPUT DETAILS | Metric | Imperial |
| Forward running | 12,00 m/min | 0,7 fps |
| Power of impact | 17 kN | 3.821,8 lbf |
| Number of blows | 689 1/min | 689 1/min |
| ELECTRICAL SYSTEM | Metric | Imperial |
| Display Equipment | Beacon | Beacon |
| Electrode distance | 0,60 - 0,70 mm | 0,024 - 0,028 " |
| Operating elements | Pushbutton OFF | Pushbutton OFF |
| ENVIRONMENT DATA | Metric | Imperial |
| Operating temperature range | -10 - 40 °C | 14 - 104 °F |
| Sound level LpA (Standard) | EN 500-4 | EN 500-4 |
| Sound power LWA, guaranteed | 108,0 dB(A) | 108,0 dB(A) |
| Storage temperature range | -30 - 50 °C | -22 - 122 °F |
| HAV summation (average value) | 10,0 m/s2 | 32,8 ft/s2 |
| Uncertainty in measurement HAV | 1,0 m/s2 | 3,3 ft/s2 |
| HAV summation (Standard) | EN 500-4 | EN 500-4 |
| Sound level LpA | 91,0 dB(A) | 91,0 dB(A) |
| Sound power LWA (Standard) | EN 500-4 | EN 500-4 |
| Sound power LWA, measured | 103,0 dB(A) | 103,0 dB(A) |
| MECHANICAL DETAILS | Metric | Imperial |
| Operating weight | 64,0 kg | 141,1 lb |
| Length | 662 mm | 26,1 " |
| Length Ramming Shoe | 340 mm | 13,4 " |
| Height | 920 mm | 36,2 " |
| Width Ramming Shoe | 280 mm | 11,0 " |
| Width | 347 mm | 13,7 " |
| Weight | 63,00 kg | 138,89 lb |
| Stroke at tamper | 68 mm | 2,7 " |
