TOFT 20-30 TON HYDRAULIC PULVERIZER FOR EXCAVATOR CAT 320 PC200

The TOFT08P delivers a maximum cutting force of 140 tons, engineered for 20 to 30-ton excavators such as the CAT 320 and PC200. As a 2025 model hydraulic pulverizer, this attachment provides significant breaking power essential for processing reinforced concrete, rock, and heavy waste materials on demanding job sites.

Successful installation depends on precise hydraulic and mechanical compatibility. The unit operates effectively with a hydraulic flow rate between 48 and 52 GPM and functions safely within a pressure range of 2900 to 3770 PSI. To mount the pulverizer correctly, verify that your excavator accommodates an 80mm pin diameter paired with a 110mm hole when no bushings are installed.

Physical measurements are critical for ensuring proper clearance and locking mechanism engagement. The assembly weighs 3600 lbs and features 311mm spacing between ears. The pin center-to-center distance measures 12.75”, while total ear length stands at 14.25” without bushings.

Technical Specifications

• Model: TOFT08P
• Excavator Capacity: 20-30 Ton
• Target Compatibility: CAT 320, PC200
• Closing Force: 140 TONS
• Pin Diameter: 80mm
• Hole Diameter: 110mm (No Bushings)
• Distance Between Ears: 311mm
• Pin Center to Pin Center: 12.75”
• Ear Length: 14.25” (No Bushings)
• Flow Requirement: 48-52 GPM
• PSI Operating Range: 2900-3770
• Total Weight: 3600 lbs
